Portable Airborne Particle Counters CLIMET CI-45xT Series

Portable Airborne Particle Counters CLIMET CI-45xT Series

. Robust Technology.
. Sample Flow Rate: 50 LPM.
. Channel Sizes: 0.3, 0.5, 1, 5 μm.
. Internal Printer.
. ISO 21501-5 compliant.

Download the product sheet

Need information

Share Product

Click here

Features

. Sample Flow Rate: 50 LPM.
. Sample Volume Control: Flow Control and internal mass flow meter ensures compliance with ISO 21501-4 Flow Rate tolerance of ± 5%. Alarm triggers if flow rate is out of compliance.
. Flow Rate Control: Electronic, automatic closed loop.
. Hepa Filtered Exhaust: All models certified to ISO Class 3.
. Laser Diode: Optimal balance of long life, stability and resolution for improved accuracy.
. Channel Sizes: 0.3, 0.5, 1, 5 μm.
. Concentration limit: 20 x 106 particles per cubic meter.
. Count Efficiency: 50% Count Efficiency (a measure of accuracy): < ±10% to Climet standards. Substantially exceeding ISO 21501-4 of < ±20%. 100% Count Efficiency (a measure of laser alignment): < ±10%. In compliance with ISO 21501-4.
. Zero count: ISO 21501-4 compliant.
. Cleaning: Compatible with common cleaning and sterization procedures, including VHP.
. Program: Up to 30 users defined and named programs, containing IDs and settings.
. Memory: 3000 samples: Date, Time, 4 Particle Channels, Flow, ID, Sample Volume, transferable to PC via RS232 serial port, Ethernet ou USB jump drive.
. Unit ID: User selectable.
. User ID: User ID: Up to 20 users, plus supervisor, with password security.
. Security: 4 security levels, with user authentication.
. Location ID: Up to 100 per program, 16 characters long.
. Cloning: All models support Unit-to-Unit, and PC-to-Unit. Cloning via USBflash drive on CI-454 model.
. Battery: 9.6 VDC, 12.6 Amp. Hour battery Operation: 4 hours with continuous sampling. Battery Recharge time: 3.5-4 hours (built-in charger).
. Wall Power: Universal 100-240 VAC Input.
. Dimensions: 21.97 x 21.6 x 24.1 cm.
. Weight: 4.99 kg without battery and 6.46 kg with battery.
. Operating Range: 0-36°C. 0-90% RH, non-condensing.

Included Accessoires and Features: All models come with an internal thermal printer, internal battery charger, battery, stainless steel isokinetic probe with 10 feet of tubing, zero count filter, two rolls of paper, cloning cable, manual, and external exhaust fitting on appropriate models. Flash drive with USB models.

Configurations: 50 LPM Particle Counters
– CI-454: External HEPA filtered exhaust, with RS232, Ethernet and USB
– CI-456: External HEPA filtered exhaust with RS232, Wi-Fi and USB

Accessories

. CI-302 High Pressure.
. Isokinetic stainless steel probe.
. Aluminum isokinetic probe.
. Scanning probe.
. HEPA filter.
. Telescopic tripod.
. Stainless steel table tripod.
. Battery.
. Battery charger.
. Thermal paper.
. Radiosterilized paper.
. Carrying case.
. Bev-a-line tubing.
. Software for downloading data.

Associated services

Equipment rental: available within 48 hours (depending availibilty). Full package including accessories, calibration certificate and consumable.

Customised IQ/OQ protocols developed according to your application.

Training session on site or in our office related to regulation, equipment use and data treatment .

Calibration and metrological services are performed in our laboratory located at Betton (35).
